Fahrtleiter Chief Scientist |
Prof. Dr. Jan H. Behrmann | ||||||
Vermessungszeitraum Survey Period |
2015/10/30 - 2015/11/24 | ||||||
Auslaufhafen Port of Departure |
Antofagasta / Chile | ||||||
Einlaufhafen Port of Arrival |
Antofagasta / Chile | ||||||
Institution | GEOMAR | ||||||
Positionierungssystem Positioning System |
|
||||||
Horizontales Datum Horizontal Datum |
WGS 84 | ||||||
Tiefenbestimmungssystem Bathymetric System |
SIMRAD EM122, ATLAS PARASOUND (Sub-Bottom Profiler) | ||||||
Vertikales Datum Vertical Datum |
Sea Level. | ||||||
Datendistribution Dataset Distribution |
|
||||||
Zitat Citation |
Bathymetriedaten der Reise SO244/1 des Forschungsschiffes Sonne. Herausgeber: GEOMAR | Helmholtz-Zentrum für Ozeanforschung, Kiel 2015 |
||||||
DOD-Referenz DOD-Reference |
20150122 |
Datensatz SO244-1.201510.A Dataset SO244-1.201510.A |
Eingangsdatum: 2016/01/20 Date of Receipt |
||
---|---|---|---|
Datenart Data Type |
Datenmenge Data Amount |
Lotungskilometer Surveyed Kilometres |
Seegebiet Sea Area |
Multibeam Data, Binary | 67056 MByte | 6650 | |
Datenformat Data Format |
Datenprozessierung Data Processing |
Schallgeschwindigkeitskorrektur Sound Velocity Correction |
|
SIMRAD EM122 (RAW&WCD) | Postprocessing software CARIS HIPS&SIPS. Position and depth processing. | A function sound velocity profile is used during the survey, check is used permanently during the survey. |
Datensatz SO244-1.201510.B Dataset SO242-2.201510.B |
Eingangsdatum: 2015/01/20 Date of Receipt |
||
---|---|---|---|
Datenart Data Type |
Datenmenge Data Amount |
Lotungskilometer Surveyed Kilometres |
Seegebiet Sea Area |
Sediment Acoustic Data, Binary |
55585 MByte (ASD.ACF-PHF) 52573 MByte (ASD.ACF-SLF) 8009 MByte (PS3-PHF) 15797 MByte (PS3-SLF) |
- | |
Datenformat Data Format |
Datenprozessierung Data Processing |
Schallgeschwindigkeitskorrektur Sound Velocity Correction |
|
ATLAS PARASOUND (ASD.ACF & PS3) | No information | No information |
