Bathymetrie der SONNE-Reise SO 280
Bathymetry of SONNE cruise SO 280

Fahrtleiter
Chief Scientist		 Dr. Saskia Brix
Vermessungszeitraum
Survey Period 		2021/01/08 - 2021/02/07
Auslaufhafen
Port of Departure 		Emden / Germany
Einlaufhafen
Port of Arrival 		Emden / Germany
Institution SAM
Positionierungssystem
Positioning System
Primäre Navigation
Prime Navaid 		Glonass/GPS
Sekundäre Navigation
Secondary Navaids 		Glonass/GPS; GPS
Fehlerabschätzung
Accuracy Assessment 		<20m
Permanent checks by nautical officers and computer staff, DGPS corrections.
Horizontales Datum
Horizontal Datum 		WGS 84
Tiefenbestimmungssystem
Bathymetric System 		SIMRAD EM122, SIMRAD EM710
Vertikales Datum
Vertical Datum 		Sea Level.
Datendistribution
Dataset Distribution
Verteiler
Distributor 		Bundesamt für Seeschifffahrt und Hydrographie
Neptunallee 5, 18057 Rostock
Datenmedium
Data Medium 		Compact Disc - CD
Digital Versatile Disc - DVD
File Transfer Protocol - FTP
Zitat
Citation 		Bathymetriedaten der Reise SO280 des Forschungsschiffes Sonne.
Herausgeber: Senckenberg am Meer Deutsches Zentrum für Marine Biodiversitätsforschung, Wilhelmshaven und Hamburg 2021
DOD-Referenz
DOD-Reference 		20210001


Datensatz SO280.202101.A
Dataset SO280.202101.A		 Eingangsdatum: 2021/02/10
Date of Receipt
Datenart
Data Type 		Datenmenge
Data Amount 		Lotungskilometer
Surveyed Kilometres 		Seegebiet
Sea Area
Multibeam Data, Binary 6930 MByte 2900 Survey line SO280
Datenformat
Data Format 		Datenprozessierung
Data Processing 		Schallgeschwindigkeitskorrektur
Sound Velocity Correction
SIMRAD EM122 (ALL & WCD) A function sound velocity profile is used during the survey. Check is used permanently during the survey. Sabird CTD sound velocity profile is used for beam correction before a survey. During transit the sound speed managertool is used, it ingests regularly updtaed SV profiles into SIS automatically taken from a world data base. Post-processing software Qimera v 2.0.1.


Datensatz SO280.202101.B
Dataset SO280.202101.B		 Eingangsdatum: 2021/02/10
Date of Receipt
Datenart
Data Type 		Datenmenge
Data Amount 		Lotungskilometer
Surveyed Kilometres 		Seegebiet
Sea Area
Multibeam Data, Binary 6262 MByte 600 Survey line SO280
Datenformat
Data Format 		Datenprozessierung
Data Processing 		Schallgeschwindigkeitskorrektur
Sound Velocity Correction
SIMRAD EM710 (ALL & WCD) A function sound velocity profile is used during the survey. Check is used permanently during the survey. Sabird CTD sound velocity profile is used for beam correction before a survey. During transit the sound speed managertool is used, it ingests regularly updtaed SV profiles into SIS automatically taken from a world data base. Post-processing software Qimera v 2.0.1.
