Fahrtleitung Chief Scientist |
Prof. Dr. Christian Winter | ||||||
Vermessungszeitraum Survey Period |
2022/10/07 - 2022/11/14 | ||||||
Auslaufhafen Port of Departure |
St. John's, Newfoundland / Canada | ||||||
Einlaufhafen Port of Arrival |
Cartagena / Colombia | ||||||
Institution Institution |
IfGK | ||||||
Positionierungssystem Positioning System |
|
||||||
Horizontales Datum Horizontal Datum |
WGS 84 | ||||||
Tiefenbestimmungssystem Bathymetric System |
SIMRAD EM122, SIMRAD EM712, ATLAS PARASOUND | ||||||
Vertikales Datum Vertical Datum |
Sea Level. | ||||||
Datendistribution Dataset Distribution |
|
||||||
Zitat Citation |
Bathymetriedaten der Reise MSM112-1 des Forschungsschiffes Maria S. Merian. Herausgeber: Institut für Geowissenschaften, Universität Kiel, Kiel 2022 |
||||||
DOD-Referenz DOD-Reference |
20220205 |
Datensatz MSM112-1.202210.A Dataset MSM112-1.202210.A |
Eingangsdatum: 2023/01/30 Date of Receipt |
||
---|---|---|---|
Datenart Data Type |
Datenmenge Data Amount |
Lotungskilometer Surveyed Kilometres |
Seegebiet Sea Area |
Multibeam Data, Binary | 13189 MByte | 1650 | |
Datenformat Data Format |
Datenprozessierung Data Processing |
Schallgeschwindigkeitskorrektur Sound Velocity Correction |
|
SIMRAD EM122 (ALL & WCD) | No filters are used. No tidal corrections. Transducer depth correction 6.5m. | In situ measurement with XVP.. |
Datensatz MSM112-1.202210.B Dataset MSM112-1.202210.B |
Eingangsdatum: 2023/01/30 Date of Receipt |
||
---|---|---|---|
Datenart Data Type |
Datenmenge Data Amount |
Lotungskilometer Surveyed Kilometres |
Seegebiet Sea Area |
Multibeam Data, Binary | 7999 MByte | 25 | |
Datenformat Data Format |
Datenprozessierung Data Processing |
Schallgeschwindigkeitskorrektur Sound Velocity Correction |
|
SIMRAD EM712 (ALL & WCD) | No filters are used. No tidal corrections. Transducer depth correction 6.5m. | In situ measurement with XVP.. |
Datensatz MSM112-1.202210.C Dataset MSM112-1.202210.C |
Eingangsdatum: 2023/01/30 Date of Receipt |
||
---|---|---|---|
Datenart Data Type |
Datenmenge Data Amount |
Lotungskilometer Surveyed Kilometres |
Seegebiet Sea Area |
Sediment Acoustic Data, Binary | 22620 MByte (ASD.ACF-PHF) 22554 MByte (ASD.ACF-SLF) 2765 MByte (PS3-PHF) 2764 MByte (PS3-SLF) 5434 MByte (SEGY-PHF) 5434 MByte (SEGY-SLF) |
- | |
Datenformat Data Format |
Datenprozessierung Data Processing |
Schallgeschwindigkeitskorrektur Sound Velocity Correction |
|
ATLAS PARASOUND (ASD.ACF & PS3 & SEGY) | No information. | No information. |
